We process 20+ engineering alloys across 7 material families, sourced domestically within China’s industrial supply chain for competitive pricing and flexible.
Mechanical Properties (Quenched & Tempered per ASTM A193):
Heat Treatment Window:
Applications: Wind turbine tower bolts (20M+ cycle fatigue), EV motor mounts, heavy machinery structural fasteners
Mechanical Properties (Q+T):
Applications: Battery pack frames, automotive chassis (non-critical)
Corrosion Performance Comparison (ASTM B117 Salt Spray)
Material | Composition (Cr-Ni-Mo) | PREN* | Salt Spray (hrs) | Max Service Temp |
304 | 18-8-0 | 18 | 500-800 | 400°C |
316L | 17-12-2.5 | 24 | 1,200-1,500 | 600°C |
Duplex 2205 | 22-5-3 | 35 | 2,000-2,500 | 300°C |
Inconel 625 | 21-61-9 (Ni-Cr-Mo) | N/A | 3,000 | 1,090°C |
*PREN = Pitting Resistance Equivalent Number: %Cr + 3.3×%Mo + 16×%N (higher = better chloride resistance)
2.1 316L Stainless Steel (Marine-Grade Standard)
Chemical Composition (ASTM A193):
C ≤0.03% | Cr: 16-18% | Ni: 10-14% | Mo: 2-3% | Mn ≤2% | Si ≤1%
Why 316L vs. 316: Low carbon (<0.03%) prevents sensitization (carbide precipitation at grain boundaries during welding/heat exposure)
Mechanical Properties (Solution Annealed per ASTM A240):
Corrosion Mechanisms Explained:
Applications: Offshore wind fasteners, marine hardware, EV battery packs (10-15 year coastal exposure)
Processing: Cold heading (50-300 pcs/min), passivation (ASTM A967 citric acid), electropolishing (Ra 0.1-0.3μm)
2.2 Duplex 2205 (Austenite + Ferrite Structure)
Key Advantage: 2× yield strength of 316L (450-550 MPa vs. 205-310 MPa) at comparable corrosion resistance
Mechanical Properties (ASTM A182 F51):
Stress Corrosion Cracking (SCC) Resistance: Superior to 300-series austenitic (critical for marine platforms under tensile stress)
Applications: Offshore platforms, desalination plants, chemical tankers
7075-T6 vs. 6061-T6 Performance Comparison
Property | 7075-T6 (Zn-Mg-Cu) | 6061-T6 (Mg-Si) | Test Standard |
Tensile Strength | 570 MPa | 310 MPa | ASTM E8 / ISO 6892-1 |
Yield Strength | 505 MPa | 275 MPa | 0.2% offset method |
Density | 2.81 g/cm³ | 2.70 g/cm³ | Both 64-65% lighter than steel |
Machinability | Good (75% rating) | Excellent (90% rating) |
|
Corrosion Resistance | Fair (requires anodizing) | Good (natural oxide) |
|
Anodizing Performance (Type III Hard Anodize per MIL-A-8625):
Max Torque Limitation: 30-50 Nm (M10 size) – suitable for decorative/moderate loads only
Ti-6Al-4V (Grade 5 per ASTM B348)
Chemical Composition:
Al: 5.5-6.75% | V: 3.5-4.5% | Fe ≤0.30% | O ≤0.20% | C ≤0.08%
N ≤0.05% | H ≤0.015% | Ti: Balance (~90%)
Mechanical Properties (Annealed per AMS 4928):
Temperature Performance:
Corrosion Immunity: Passive TiO₂ layer (2-7 nm, self-healing) → infinite salt spray resistance
Processing Challenges Solved:
Weight Savings Example: M8×25mm bolt: Ti 4.5g vs. Steel 8.0g = 540g savings per 40-bolt engine kit
Applications: Racing engine bays, aerospace fasteners, premium builds
Inconel 718 (Age-Hardenable Ni-Cr per AMS 5662)
Chemical Composition:
Ni: 50-55% | Cr: 17-21% | Fe: ~18% | Nb+Ta: 4.75-5.50% | Mo: 2.80-3.30%
Ti: 0.65-1.15% | Al: 0.20-0.80% | Co ≤1% | C ≤0.08%
Mechanical Properties (Solution + Aged per ASTM B637):
High-Temperature Strength Retention:
Temp (°C) | Inconel 718 Tensile | 42CrMo4 Tensile | Advantage
20 | 1,350 MPa | 1,100 MPa | Baseline
400 | 1,200 MPa | 600 MPa | +100%
650 | 950 MPa | 180 MPa | +428%
Applications: Turbo mounting bolts (800-1,000°C exhaust gas), jet engines, industrial gas turbines
Stock Availability: Inconel 718 bar stock (Ø8-50mm) maintained for 1-2 week rapid prototyping (vs. 4-6 week procurement)
Processing: 15-30 m/min speeds (vs. 200+ for aluminum), ceramic/fresh carbide tools, 80-120 bar coolant
Our Material | ASTM | EN | GB (China) | JIS | Application |
42CrMo4 | A193 Grade B7 | EN 10083-3 | GB 42CrMo | SCM440 | Wind turbine, industrial |
316L SS | A193 Grade B8M Class 2 | EN 1.4404 | GB 022Cr17Ni12Mo2 | SUS316L | Marine, offshore |
Ti-6Al-4V | B348 Grade 5 | EN 3.7165 | GB TC4 | TAB6400 | Aerospace, racing |
7075-T6 Al | B211 | EN AW-7075 | GB 7A04 | A7075 | Lightweight structural |
Inconel 718 | B637 UNS N07718 | EN 2.4668 | GH4169 | NCF718 | Extreme temperature |
Material Verification:
Test Frequency: 2 tensile samples + 5 hardness measurements per production batch
